The double-rotor rake STAR 600 | 20 T is designed for ease of use and high productivity.
The modular rotors with four pairs of spring tines on each holder allow forming two single swaths or one double swath. The innovative walking tandem axle and height-adjustable double-bearing rotors ensure ground tracking and efficiency in all working conditions.
PARALLELOGRAM LINKAGE
The hitch ring is controlled by parallel linkage. The hydraulic arm on the drawbar maintains the leading rotor parallel to the ground as it is lifted and lowered.
MODULAR ROTOR
The advantages of the modular rotor are individually replaceable spring tine holders, a large cam track, quality materials, minimal maintenance and a long service life.
EASY ROTOR HEIGHT ADJUSTMENT
Easy and simple rotor height adjustment with a threaded bolt.
HYDRAULIC CONTROL OF REAR ROTOR
Hydraulic control of the rear rotor with an option of two single swaths (1) or a double swath on the left side (2).
Swath width: 0,6-1,20 m.
3D PIVOTING MOUNTING OF REAR ROTOR
The 3D pivoting mounting of the rear rotor on the parallelogram frame undercarriage allows perfect ground tracking. The rear rotor is operated hydraulically for quick and efficient raking.
SIP WALKING TANDEM
The front rotors are equipped as a standard with a SIP walking tandem axle (SIP patent), which enables optimal adaptation to terrain, higher working speed and lower load transfer to the machine.
| Working width | 3.40–6.20 / 6.00 |
| Swath width | 0.60 - 1.20 |
| No. of tine arms per rotor (machine) | 2x10 (20) |
| No. of spring tines per arm | 4 |
| Rotor diameter | 2.85 |
| PTO rotation speed | 540 |
| Recommended PTO rotation speed | 350 - 450 |
| Masa | 1480 |
| Required Tractor power | 30/40 |
| Capacity | 8.00 |
| Safety clutch | 900 |
| Transport width | 2.25 - 2.99 |
| Transport height (folded protection railing) | 1.50 |
| Transport lenght | 7.64 - 8.23 |
| Wheels | 18x8.50 - 8 |
| Parallelogram drawbar | ICON |
| PTO shatf with safety clutch | ICON |
| 1x single-acting hydraulic connection (1SA), 1x double-acting hydraulic connection (1DA) | ICON |
| Swath curtain | ICON |
| Mechanical working height adjustment | ICON |
| Walking tandem axle (SIP patent) | ICON |
| Hydraulic lift of rotors | ICON |
